热卖京明树NF-801R电缆测试仪、网络电缆跟踪器、网络电缆测试仪，电线测试仪，测试仪器，电工多功能套件，阻燃，PoE

**Product Specifications:**

**Brand:** NOYAFA

**Model:** NF-801R

**Type:** Multifunctional Line Meter

**Features:**

- Multifunctional network cable tester for line tracing and testing

- RJ45 and RJ11 compatible

- Line tracing and testing with RJ45 and RJ11 interfaces

- Line sequence checking with 9 LED indicators

- Line polarity detection with positive and negative pole testing

- Illumination function for low-light environments

- Color options: Red (Model: NF-801R), Blue (Model: NF-801B)

**Components:**

1. Tool kit

2. Transmitter

3. Receiver

4. 9V batteries x 2

5. RJ11 interface telephone line

6. RJ11 alligator clip line

7. RJ45 interface network cable

8. User manual

9. Color box

**Technical Specifications:**

- Power Supply: DC 9V battery

- Power Consumption: 15mA

- Maximum Operating Current: Transmitter ≤ 10mA, Receiver < 30mA

- Signal Transmission Format: Multi-audio pulse

- Signal Output Frequency: 8Vp-p

- Compatible Cable Types: Twisted pair, video cable, telephone line, common metal wire

- Compatible Ports: RJ11 (telephone line), RJ45 (network cable)

- Testing Range: Up to 1000 meters

**Dimensions:**

- Transmitter: 42mm x 49mm x 175mm

- Receiver: 42mm x 49mm x 126mm

**Operation Instructions:**

- Line Tracing: Insert network cable into RJ45 interface, switch to line tracing mode, and follow audio and visual cues to trace the cable

- Line Sequence Checking: Insert network cable into RJ45 interface, switch to line sequence checking mode, and observe LED indicators for correct wiring sequence

**Additional Features:**

- Equipped with a headphone jack for noisy environments

- Comes with alligator clips for metal wire tracing

**Compatibility:** Suitable for RJ45 and RJ11 interfaces

**Release Date:** August 2020

This multifunctional network cable tester from NOYAFA, model NF-801R, is designed for efficient line tracing, line sequence checking, and network cable testing. It offers a range of features such as illumination function, color options, and easy-to-use operation instructions, making it a versatile tool for network professionals.
