**Product Specifications:**
**Brand:** EB-LINK
**Description:** Third generation USB 3.1 expansion card
**Data Rate:** 10Gbps
**Ports:** Type-C + Type-A
**Power Supply:** 4A independent power supply, no external power required
**Compatibility:** USB 3.1 (10Gbps), USB 3.0 (5Gbps), USB 2.0 (480Mbps)
**Controller Chip:** High-performance ASM3142 controller chip
**Features:** Supports USB 3.1 dual ports, up to USB 3.1 Gen-II 10Gbps
**Protection:** Over-current and over-voltage protection for each port
**Compatibility:** Widely compatible with PCI-E X4/X8/X16 slots
**Voltage Regulation:** Independent stable voltage regulation for each port
**Heat Dissipation:** Enhanced heat dissipation with larger heat sink
**Connector:** Thickened gold-plated fingers for reliable connection
**Operating Systems:** Compatible with Windows 7/8/8.1/10 and most mainstream operating systems
**Installation:** Compatible with standard desktop computers, easy installation process
**Technical Specifications:**
**Processor Chip:** ASM3142
**Transfer Rate:** 10Gbps
**Bus Rate:** 16GT/s
**Interface Speed:** Approximately 1000MB/s
**Expansion Interface:** Type-C + USB 3.1
**Interface Type:** PCI-E X4 (not compatible with PCI slots)
**Product Dimensions:** 120*80*57mm
**Compatible Models:** Standard desktop computers
**Installation Guide:**
1. Open the computer case and remove the side panel.
2. Unscrew the case screws and remove the side cover.
3. Remove the corresponding slot cover for the PCI-E slot where the card will be inserted (PCI-E X4/X8/X16 supported).
4. Insert the expansion card into the appropriate slot.
5. Secure the card with screws to the case.
6. Test functionality and replace the side cover.
For detailed compatibility and inquiries, please contact customer service.
