Specifications:
Brand: EB-LINK
Product Name: PCI-E to SATA3.0 6-Port Expansion Card
Main Control Chip: ASM1166
Product Interface: 6*SATA interfaces
Driver Installation: Plug and Play
Interface Rate: 6Gbps
Bus Rate: 20Gbps
Input Voltage: DC 3.3V
Input Current: 300mA
Power Supply: PCI-E
Supported Slot: PCI-E 3.0 X4 (supports x8x16) slot
Operating Environment: 0°C~60°C (in use), 20°~80°C (storage)
Product Dimensions: Bracket 120mm * Length 80mm * Width 67mm
Supported Operating Systems: WIN7, 8, 10, 11, Linux
Functional Parameters: Supports IDE/AHCI mode, hot-swappable, plug and play
Please note:
1. Do not install the adapter card in the PCI slot, as misplacement may damage the adapter card, hard drive, and motherboard.
2. The PCI-E slots on 915, 945, G31/G41 series motherboards are version 1.0, providing only 200M speed and cannot be accelerated.
For more information, please refer to the product manual.
