**Product Specifications:**
**Brand:** EB-LINK
**Model:** Wireless LAN Card WiFi7
**Wireless Standards:** WiFi7, Bluetooth 5.4
**Transmission Speeds:** 2.4GHz: 574Mbps, 5.8GHz: 2400Mbps, 6GHz: 5800Mbps
**Features:** Simulation function of AP, Intel chips, movable external antenna
**Frequency Bands:** 2.4GHz, 5.8GHz, 6GHz
**Channel Width:** 320MHz
**Interface:** PCI-Express X1
**Compatibility:** Windows 10/11/12 (64-bit)
**Dimensions:** Antenna - 218mm x 80mm, LAN Card - 77mm x 55mm
**Additional Features:** MU-MIMO, Transmit Power: 20dBM
**Supported Protocols:** IEEE802.11ax/ac/be, IEEE802.11a/b/g/n
**Wireless Frequency Bands:** 2.412GHz-2.4835GHz, 5.150GHz-5.825GHz, 5.925GHz-7.125GHz
**Encryption:** WPA/WPA2/WPA3/WPA4/WEP
**Package Contents:**
Wireless LAN Card x1
Bluetooth Cable x1
Magnetic External Antenna x1
Half-height Bracket x1
Screwdriver x1
Screws x1
User Manual x1
**Installation Guide:**
1. Connect the Bluetooth cable to the motherboard's 9-pin USB interface.
2. Remove the corresponding bracket from the PCI-E slot on the motherboard.
3. Insert the LAN card into the PCI-E slot and secure it.
4. Connect the 9-pin Bluetooth cable to the motherboard interface and the 4-pin to the LAN card interface.
5. Close the computer case, attach the antenna, and the card is ready for use.
**Note:** Ensure compatibility with PCI-E (X1/X4/X8/X16) slots. Do not use in a PCI slot to avoid damaging the card.
